ALIEN Hydroponics V-SYSTEM 18 Pot 3 Row Kit

Product image 1
Product image 2
Product image 3
Product image 4

ALIEN Hydroponics V-SYSTEM 18 Pot 3 Row Kit

Description
  • Direct nutrient distribution: The V-SYSTEM benefits from distributing nutrients directly to your plants.
  • Maximum oxygen saturation: Ensures optimum levels of oxygen are reaching your plants.
  • No air pump needed: This system is developed to need no external air pump.
  • No heat transferred: The design makes sure that no unnecessary heat is transferred to your plants.

  • Vortex fluid motion: The fluid moves in a vortex-like pattern, ensuring even distribution.
  • Naturally aspirated: The V-SYSTEM is naturally aspirated, enhancing its productivity.
  • Supports large plants: The system is designed to support the growth of large plants as well.
  • Pots and system completely drain: Pots and systems have been designed for complete drainage, preventing any waterlogging.

  • Prevents root clogging: The design is set to prevent any sort of root clogging that could hamper the growth of your plants.
  • Made in Britain: The V-SYSTEM is proudly made in Britain.

  • Key V-SYSTEM Features:
  • 15 gallon (58L) V-POT: Gives sufficient space for steady growth.
  • Water fill line: A water fill line is included to control water levels.
  • Total-drainage bases: The bases are designed for total-drainage, preventing any stagnation.

  • Venturi injectors: The venturi injectors help in improving the airflow.
  • Inspection Covers: Easy-to-use covers for reviewing the growth process.
  • 5" spiral tubing: An efficient spiral tubing for optimal growth conditions.
  • 5" Dual-Flow™ fittings: Fitted with Dual-Flow system for maximizing efficiency.

  • Integrated filtration: The V-SYSTEM comes with an integrated filtration system that keeps your setup clean and free from any obstructions.
  • T304 Stainless clamps: These heavy-duty clamps ensure that everything stays together perfectly.
  • Heavy-duty components: The high-quality, heavy-duty components of the V-SYSTEM guarantee a longer lifespan and flawless operation.
  • Push-fit feed connections: These connections ensure the easiest compatibility with your existing setup.
  • JET-STREAM® Vortex™ pump: The system includes a phenomenal JET-STREAM® Vortex™ pump that ensures an even nutrient distribution and maximum oxygen saturation without the need of an air pump.
    • Specifications
  • Product Name: V-SYSTEM 18 Pot 3 Row Kit

  • Technical Information
  • Number of pots: 18
  • Number of rows: 3

  • Kit total fluid volume: 293.8 gallons (1112 L)

  • Minimum assembled size (can space pots more widely for a larger footprint):
  • Length: 12' 1.3" (145.3 inches / 3690 mm)
  • Width: 5' 9.3" (69.3 inches / 1760 mm)

  • Water Pump Included with the Kit:

  • Model: V-SYSTEM Vortex Water Pump 1100W 120V 17700 l/h
  • Wattage: 1100 watts
  • Flow Rate: 4676 gal/hr (17700 L/hr)

  • Recommended water chiller minimum capacity: 528 gallons (2000 L)
    • Data Sheet
  • Download the instruction manual: here
  • Download the technical drawing: here
    • Kit Contents
  • The V-SYSTEM 18 Pot 3 Row Kit Includes:
  • 1 x V-SYSTEM Vortex Water Pump 1100W 120V 17700 l/h
  • 18 x V-Pot 58L
  • 18 x V-Pot Base
  • 18 x V-Pot Lid
  • 18 x V-Pot Lid Inspection Cover
  • 18 x Square Net Pot
  • 18 x V-Pot Clip
  • 18 x Air Filter for V-SYSTEM Venturi, 6mm
  • 18 x Silencer for Venturi
  • 18 x Venturi Fitting
  • 18 x Venturi Air Inlet Pipe 6mm Blue (2X 4")
  • 18 x Venturi Inlet Fitting for 22mm Pipe
  • 19 x Nut 5"
  • 19 x Washer 5" Green Silicone
  • 44 x 5" Stainless Steel Clamp
  • 1 x Distribution Tee 40mm
  • 3 x DM Push-Fit Elbow 22-15mm V-SYSTEM
  • 3 x DM Push-Fit Elbow 22mm V-SYSTEM
  • 15 x DM Push-Fit Tee 22-15mm V-SYSTEM
  • 1 x 1/2" Drain Cap Fitting
  • 1 x Drain Tap 1/2"-16mm Barb
  • 2 x Elbow 5" Barbed with Drain Point
  • 4 x Elbow 5" Threaded Dual-Flow
  • 1 x Filter Manifold Complete 40mm
  • 1 x Float Valve
  • 1 x V-SYSTEM Header Pot 20L 40mm
  • 1 x Silver Lid
  • 1 x Header Pot Blank
  • 1 x Hosetail 16mm-3/4" Female Green
  • 18 x Pipe 22mm Gray Rigid 1 Meter - Venturi Feed
  • 1 x Pipe 32mm Red 1 Meter Spiral
  • 4 x Pipe 40mm Silver 1 Meter Spiral
  • 19 x Pipe 5" Silver Spiral 80cm
  • 2 x Tee 5" Barbed
  • 15 x Tee Threaded 5" Dual-Flow
  • 2 x Threaded Tank Connector 1"
  • 1 x Vortex Pump Inlet Manifold 40mm Short
  • 2 x 1" Cap for Chiller Connections
  • 1 x Tank Connector Straight 32mm
  • 1 x Tank Connector Straight 40mm
  • 1 x Terminal Manifold Left 40mm
  • 1 x Terminal Manifold Center 40mm
  • 1 x Terminal Manifold Right 40mm
  • 42 x 22mm Insert for 22mm Rigid Pipe
  • 2 x Clamp Size 2
  • 10 x Clamp Size 3
  • 1 x 8mm Screwdriver for 5" Clamp
  • 1 x Wrench 5"
  • 1 x Wrench for Float Valve
  • 1 x 8mm Socket for 5" Clamp
  • 1 x Pipe Cutter 50mm
  • 5 x Silicone Grease - Food Grade
    • $6,433.83
