Type K Ambient Thermometer Probe

Product image 1
Product image 2
Product image 3

Type K Ambient Thermometer Probe

The primary difference between Type J and Type K thermocouples is the measuring range, and the sensitivity. Type K is the most common general-purpose thermocouple with a sensitivity of approximately 41 µV/°C. A wide variety of probes are available in its −50°C to +900°C / -58°F to +1652°F range. Type K wire color standard is yellow (+) and red (-). Type J has a more restricted range of −50 to +400°C, but higher sensitivity of about 50 µV/°C. Type J wire color standard is white (+) and red (-).

Specifications

Ambient
Type Application Temperature Range Accuracy
K Beaded wire for fast response in air and gas in difficult to access areas -50 to 300ºC
-58 to 572ºF
Max. short-term operating temperature: 250°C (482°F)		 ± 0.4%
It is an ultra fast response naked-bead thermocouple suitable for many general purpose applications.
Dimensions Cord Length: 47"

Comparison Chart



$6.60

Original: $22.00

-70%
Type K Ambient Thermometer Probe—

$22.00

$6.60

Product Information

Shipping & Returns

Description

The primary difference between Type J and Type K thermocouples is the measuring range, and the sensitivity. Type K is the most common general-purpose thermocouple with a sensitivity of approximately 41 µV/°C. A wide variety of probes are available in its −50°C to +900°C / -58°F to +1652°F range. Type K wire color standard is yellow (+) and red (-). Type J has a more restricted range of −50 to +400°C, but higher sensitivity of about 50 µV/°C. Type J wire color standard is white (+) and red (-).

Specifications

Ambient
Type Application Temperature Range Accuracy
K Beaded wire for fast response in air and gas in difficult to access areas -50 to 300ºC
-58 to 572ºF
Max. short-term operating temperature: 250°C (482°F)		 ± 0.4%
It is an ultra fast response naked-bead thermocouple suitable for many general purpose applications.
Dimensions Cord Length: 47"

Comparison Chart
